IDS1000-A Air-Cooled Container Data Center
All-in-One Maintenance Guide
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
If the magnetic lock indicator is green when the container door is closed and red when the door is open,
the magnetic lock is working properly.
----End
Follow-up Procedure
Dispose of the removed magnetic lock that is confirmed faulty.
5.3.13.4 Replacing the Electronic Lock
Prerequisites
A electronic lock needs to be replaced.
A spare electronic lock of the same model is available functions properly.
Impact on the System
None
Preparations
Tools: Phillips screwdriver, step ladder (2 m)
Material: spare electronic lock
Documents required: none
Skill requirement: weak-current engineer
Procedure
Step 1 Use a Phillips screwdriver to loosen screws from the baffle plate of the electronic lock and
remove the baffle plate, as shown in Figure 5-32.
Figure 5-32 Removing the baffle plate
