Figure 3-62 Removing an emergency door release button
1. Remove screws from the emergency door release button using a Phillips screwdriver, as
shown by (1) in Figure 3-62.
2. Remove the glass panel of the emergency door release button, as shown by (2) and (3) in
Figure 3-62.
3. Remove screws from the base, and remove the base, as shown by (4) in Figure 3-62.
Step 2 Mark the mounting holes using a marker and the base.
Figure 3-63 Marking mounting holes (unit: mm)
Step 3 Drill holes using a hammer drill, and route cables out of the cable hole.
Step 4 Install the emergency door release button.
