NOTE
Because the management VLAN and the management IP address have been configured, you can run the telnet
192.168.50.2 command on the OLT to log in to the ONU to perform the configuration. You can also log in to
the ONU through a serial port to perform the configuration.
1. Log in to the ONU to perform the configuration.
On the OLT, use the management IP address of the ONU to log in to the ONU through
Telnet. User name: root (default). Password: mduadmin (default).
huawei(config)#telnet 192.168.50.2
{ <cr>|service-port<U><0,4294967295> }:
Command:
telnet 192.168.50.2
Press CTRL_] to quit telnet mode
Trying 192.168.50.2 ...
Connected to 192.168.50.2 ...
>>User name:root
>>User password: //It is not displayed on the console.
2. Configure the dual PON ports upstream mode.
When GPON type C dual-homing protect is configured, set the two PON uplink ports to
be in the active/standby mode. Run the display pon config command to query the working
mode of the two ports. The two ports work in active/standby mode by default. Run the pon
uplink-mode active-standby command to set the mode.
huawei(config)#pon uplink-mode active-standby//Determine whether to run this
command based on the dual PON ports upstream mode
3. Configure a traffic profile.
The same port is used for transmitting power distribution site information and GOOSE
packets. Therefore, the 802.1p priority of each service needs to be set. The priority of power
distribution site information is lower than that of GOOSE packets. Set the traffic profile
index of power distribution site information to 10 and the priority to 1; set the traffic profile
index of GOOSE packets to 11 and the priority to 6.
huawei(config)#traffic table ip index 10 cir off priority 1 priority-policy
local-Setting
Create traffic descriptor record
successfully
------------------------------------------------
TD Index :
10
TD Name : ip-traffic-
table_10
Priority :
1
Copy Priority :
-
CTAG Mapping Priority:
-
CTAG Default Priority:
0
Priority Policy : local-
pri
CIR :
off
CBS :
off
PIR :
off
PBS :
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
17 Electrical Service Configuration
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
1843
