huawei(config-if-vdsl-0/2)#vdsl line-profile quickadd 11 transmode 1 snr 70 0
300 70 0 300
2. All parameters following vdsl-parameter are VDSL parameters in contrast to ADSL.
These parameters do not need to be configured in the case of the ADSL Internet access
service. However, in the case of the VDSL Internet access service, these parameters need
to be configured according to actual conditions. The default G993.2 profile is profile 12a,
which is consistent with the required profile in this example. Hence, no modification is
required.
Step 4 Run the display vdsl channel-profile command to query the data path mode and line rate in the
channel profile.
huawei(config-if-vdsl-0/2)#display vdsl channel-profile
10
------------------------------------------------------------------------------
Profile index: 10 Name: VDSL CHANNEL PROFILE 10
Data path mode : ATM
Minimum impulse noise protection downstream : NoProtection
Minimum impulse noise protection upstream : NoProtection
Maximum interleaving delay downstream(ms) : 20
Maximum interleaving delay upstream(ms) : 20
Minimum transmit rate downstream(Kbps) : 32
Minimum reserved transmit rate downstream(Kbps) : 32
Maximum transmit rate downstream(Kbps) : 200000
Minimum transmit rate upstream(Kbps) : 32
Minimum reserved transmit rate upstream(Kbps) : 32
Maximum transmit rate upstream(Kbps) : 200000
---- More ( Press 'Q' to break ) ----
If the line rate does not meet the requirements of users, change it. To do so, proceed to Step 5.
Step 5 Run the vdsl channel-profile quickadd command to reconfigure the data path mode and line
rate.
To meet customer demands, increase bandwidth to 8192 kbit/s, set the data path mode to both
and add a new channel profile (channel profile 11).
huawei(config-if-vdsl-0/2)#vdsl channel-profile quickadd 11 path-mode both rat
e 32 81920 32 2048
Step 6 Bind the required VDSL2 line template 11 to port 0/2/4.
NOTE
By default, a port is in the activated state. Before binding a template to the port, you must deactivate the port.
huawei(config-if-vdsl-0/2)#vdsl line-template quickadd 11 line 11 channel1 11 100
100
huawei(config-if-vdsl-0/2)#deactivate 4
huawei(config-if-vdsl-0/2)#activate 4 template-index 11
huawei(config-if-vdsl-0/2)#quit
Step 7 Add a traffic profile.
1. Run the display traffic table ip command to query the existing traffic profiles in the system.
huawei(config)#display traffic table ip from-index 0
{ <cr>|to-index<K> }:
Command:
display traffic table ip from-index 0
---------------------------------------------------------------------------
TID CIR CBS PIR PBS Pri Copy-policy Pri-Policy
(kbps) (bytes) (kbps) (bytes)
---------------------------------------------------------------------------
0 1024 34768 2048 69536 6 - tag-pri
1 2496 81872 4992 163744 6 - tag-pri
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
3 Configuring the DSLAM Services
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
290
