Specifications
Appendix
Acceptable RGB Input/Output Signals
ViewPoint 8050 Videoconferencing Terminal (RGB IN)
* Cannot be transmitted by the ViewPoint 8050-DSB Dual Stream Box.
ViewPoint 8050-DSB Dual Stream Box (RGB IN) (Connector located on ViewPoint 8050)
ViewPoint 8050-DSB Dual Stream Box (RGB OUT)
* While the picture input from the RGB IN connector is transmitted, the picture of the input signal format (VGA, SVGA or XGA) is output from this connector.
Picture element Signal format fH (kHz) fV (Hz) Dot clock (MHz) Sync
640 × 480 VGA mode 31.469 59.94 25.17 H-neg V-neg
Macintosh 13" 35 66.667 30.24 H-neg V-neg
VGA VESA 72 Hz 37.861 72.809 31.5 H-neg V-neg
VGA VESA 75 Hz 37.5 75 31.5 H-neg V-neg
VGA VESA 85 Hz 43.269 85.008 36 H-neg V-neg
800 × 600 SVGA VESA 56 Hz 35.156 56.25 36 H-pos V-pos
SVGA VESA 60 Hz 37.879 60.317 40 H-pos V-pos
SVGA VESA 72 Hz 48.077 72.188 50 H-pos V-pos
SVGA VESA 75 Hz 46.875 75 49.5 H-pos V-pos
SVGA VESA 85 Hz 53.674 85.061 56.25 H-pos V-pos
1024 × 768 XGA VESA 60 Hz 48.363 60.004 65 H-neg V-neg
XGA VESA 70 Hz 56.476 70.069 75 H-neg V-neg
XGA VESA 75 Hz 60.023 75.029 78.75 H-pos V-pos
1280 × 768 WXGA VESA 60 Hz* 47.693 59.992 80.12 H-neg V-pos
Picture element Signal format fH (kHz) fV (Hz) Dot clock (MHz) Sync
640 × 480 VGA mode 31.469 59.94 25.17 H-neg V-neg
Macintosh 13" 35 66.667 30.24 H-neg V-neg
VGA VESA 72 Hz 37.861 72.809 31.5 H-neg V-neg
VGA VESA 75 Hz 37.5 75 31.5 H-neg V-neg
VGA VESA 85 Hz 43.269 85.008 36 H-neg V-neg
800 × 600 SVGA VESA 56 Hz 35.156 56.25 36 H-pos V-pos
SVGA VESA 60 Hz 37.879 60.317 40 H-pos V-pos
SVGA VESA 72 Hz 48.077 72.188 50 H-pos V-pos
SVGA VESA 75 Hz 46.875 75 49.5 H-pos V-pos
SVGA VESA 85 Hz 53.674 85.061 56.25 H-pos V-pos
1024 × 768 XGA VESA 60 Hz 48.363 60.004 65 H-neg V-neg
XGA VESA 70 Hz 56.476 70.069 75 H-neg V-neg
XGA VESA 75 Hz 60.023 75.029 78.75 H-pos V-pos
Picture element Signal format fH (kHz) fV (Hz) Dot clock (MHz) Sync
1024 × 768 XGA VESA 60 Hz 48.363 60.004 65 H-neg V-neg
