112
Specifications
Appendix
Pin Assignment
100BASE-TX/10BASE-T port
Modular port
RGB IN connector
Mini D-sub 15-pin (female)
RS-232C connector
D-sub 9-pin (male)
Mouse connector
Mouse connector
PC connector
PC connector
Pin Signal Description
1 TPOPTX+ Transmit+
2 TPONTX- Transmit-
3 TPIPRX+ Receive+
4NC -
5NC -
6 TPINRX- Receive-
7NC -
8NC -
Pin Signal Description
1 RED R (red)
2 GREEN G (green)
3 BLUE B (blue)
4NC -
5 GDN Ground
6 RED. GND R (red) signal ground
7 GREEN. GND G (green) signal ground
8 BLUE. GND B (blue) signal ground
9NC -
10 SYNC. GND Sync signal ground
11 NC -
12 NC -
13 HSYNC Horizontal sync
14 VSYNC Vertical sync
15 NC -
18
15 11
51
10 6
Pin Signal Description
1NC -
2RD Receive
3TD Transmit
4NC -
5 GND Ground
6NC -
7NC -
8NC -
9NC -
Pin Signal Description
1 Vbus Power
2 -Data (D-) Transmit/receive data-
3 +Data (D+) Transmit/receive data+
4 GND Ground
Pin Signal Description
1 Vbus Power
2 -Data (D-) Transmit/receive data-
3 +Data (D+) Transmit/receive data+
4 GND Ground
15
69
14
12
34
