English – 17
4.6.1 Lift lever for the cutting deck
The lift lever is used to set the cutting deck in
transport or mowing position. If the lift lever is pulled
rearwards the deck raises and the blades
automatically stop to rotate (transport position).
If the lift lever is mowed forwards the cutting deck
lowers and the blades automatically start to rotate.
(mowing position)
The cutting height can be adjusted to 8 dierent
positions with the cutting height lever. See “5.7.6
Adjusting the cutting height range” on page 59.
4.6 Cutting deck
The entire Rider series have a front-mounted cutting
deck in order to move eciently even in conned
areas.
This product comes supplied with a Combi 112
cutting deck wich can be used in collect mode and
non-collect mode. See Operator’s manual for more
information.
Design and Function
