60 – English
5.7.7 Checking and adjusting ground
pressure
To get the best mowing result it is important to have
correct pressure from the cutting deck on the
underlying surface.
1. Make sure that the air pressure in the tyres is
150kPa (1.5 bar / 21.8 PSI).
2. Park the product on level surface.
3. Lower the cutting deck to the mowing position.
4. Place a set of bathroom scales under the front
edge of the cutting deck.
5. To make sure that the support wheels do not bear
weight, put a block between the frame and the
scales.
6. To adjust the ground pressure, turn the adjusting
screws fountd behind the front wheels on the
right and left side.
7. Turn the screws right or left until the ground
pressure is between 12 and 15 kg (26.5-33 Ib).
Cutting system
