66 – English
5.9 Auger
5.9.1 Remove the auger kpl
Removal
1. Pull the auger servicing position lever in NOT
service mode.
2. Till the seat and the collector.
3. Disconnect the cable from the socket and remove
the plastic cover.
4. Remove the belt from the pulley, start from the
right side.
5. Remove the belt from the solenoid clutch.
6. Place the belt accordiing to the picture.
7. Raise the visor and locked in place with a screw.
8. Remove the auger.
Assembly
Do the above instructions in opposite sequence.
Auger
