Husqvarna RC 318T Workshop Manual

English – 67
5.9.2 Remove the auger from auger kpl
Removal
1. Remove the auger kpl from the product, see
“5.9.1 Remove the auger kpl” on page 66.
2. Remove the screw and lift o󰀨 the belt cover. (1)
3. Remove the belt and the belt pulleys, see “5.9.3
To remove the auger belt and gear wheels” on
page 68.
4. Remove the 4 screws and lift o󰀨 the bracket. (2)
5. Remove the screw. (3)
6. Remove auger. (4)
Assembly
Do the above instructions in opposite sequence.
1
2
4
3
Auger
