Set Slope Factor
1. Turn the Upper Line knob until you see:
The lower line of the display shows the default setting.
2. Turn the Lower Line knob to choose one of the following slope
factors:
• None/Slight 0-5% Grade (Default Setting),
• Gentle 6-8% Grade,
• Mild 9-12% Grade,
• Moderate 13-20% Grade or
• Steep > 20% Grade.
Set Sprinkler Location
1. Turn the Upper Line knob until you see:
2. Turn the Lower Line knob to choose one of the following
locations of sprinklers with relationship to the slope:
• None, No Slope Set (Default Setting if no slope),
• All Parts of Slope (Default Setting if slope > none),
• Top of Slope,
• Middle of Slope or
• Bottom of Slope.
