INSTALLATION MANUAL
FOR ELECTRICAL PARTS
• During the low speed operation for installation, Do not insert CAN
communication line into MAIN Board. CN11 and CN12 in order to prevent
CAN parts damage
• If you need to connect CAN communication line connectors CN11 and CN12,
insert the connector after turning the power OFF in order to prevent CAN parts
damage)
• Make sure to wire the inverter input power lines(R, S, and T), output power
lines (U, V, W), damping resistance power lines (P, BK) and signal lines with
long enough intervals.
