INSTALLATION MANUAL
FOR ELECTRICAL PARTS
⑰ When the connection between the communication line and the interlock harness cable or the button
cable is completed, arrange the cable to prevent interference with door panel operation or CAR
operation, operate CAR down to the next floor and stop CAR at the location for easy working, and
repeat the above ⑦~⑨works.
⑱ For the lowest floor, perform the following works.
• Interlock connection at the lowest floor
Connect the 2 pin connector that came through the lowest floor interlock to the interlock
connector taken out from the pit harness.
• Communication line connection at the lowest floor
For the lowest floor, insert the communication line came down from the lowest floor+1 to HIP or
CH1 of HPI board, and insert the end connector into CH4.
• If temporary monitoring panel is installed :
Remove CH4 end resistor, and connect CAN-repeater to CH4.
(End resistor is included inside CAN-repeater, so no separate end resistor is necessary)
⑲ Work at the pit
Connect bottom part Final limit switch connector.
Connect the connector to be connected to the pit switch box.
To Next Page
