INSTALLATION MANUAL
FOR ELECTRICAL PARTS
IMPORTANT! HANDICAPPED SETTING :
Remove the jumper at REAR DIP of HIP or HPI board.
① During the connection of HIP (HPI) cable, check if there is a reversed connection, disconnection, or
short-circuit of P24, N24, CH, CL, etc.
② Check if DC24V power is normal.
③ Floor input setting should not overlap with another floor.
④ During the connector connection and disconnection, work after turning the power OFF.
⑤ Manage the site thoroughly to prevent the damage of the material.
