INSTALLATION MANUAL
FOR ELECTRICAL PARTS
1.5 VCON Board
Brake control power input
AC220V(for rectification) /
DC24V(for control)
Safety line DC110V output
Brake voltage fixed/variable selection
Before adjusting voltage,
turn ON all the jumper switches.
Brake voltage adjustment resistance
If it is turned clockwise,
voltage increases.
Holding output voltage Type selection
When 1-2 jumper is made, activation /
holding voltage is generated.
