Hyundai Elevator WBVF - Page 82

WBVF
A ． INSTALLATION MANUAL
FOR ELECTRICAL PARTS
Doc. No
Ver.
11.0
Date
2019-04-02
Page
82 / 98
2.2 WCOP30 / WCOP62 Board
It is used for Handicapped button input and button expansion.
WCOP30 / WCOP62 Board
No.
Name
Description
Remark
2
COMM LED
It blinks when there is no problem on CAN COMM
LD1
3
Power /
communication
Connecting
part
PIN No.
Contents
3
Power /
communication
Connecting
part
1
P24
2
CAN H
CAN HIGH
3
CAN L
CAN LOW
4
N24
board power
11
Usage setting
SWITCH
(SW1)
Front
Rear
Description
ALL OFF
2,3 ON
Handicap button input 1
1~30
th
floor,
WCOP30
1 ON
1,2,3 ON
Handicap button input 2
1~30
th
floor,
2 ON
4 ON
MAIN COP expansion
1~62
th
floor,
WCOP62
1,2 ON
1,4 ON
SUB COP expansion
1~62
th
floor,
ALL OFF
2,3 ON
Handicap button input 1
1~62
th
floor,
1 ON
1,2,3 ON
Handicap button input 2
1~62
th
floor,
2 ON
2,4 ON
MAIN COP expansion
1~62
th
floor,
WCOP30D
1,2 ON
1,2,4 ON
SUB COP expansion
1~62
th
floor,
4
Button
connecting
part
30 buttons are connected. (WCOP30)
62 buttons are connected. (WCOP62)
The number of
hall buttons is
applied by the
usage setting.
15
UP lantern
UP lantern output in the Car
CN_W2
