WBVF
A ． INSTALLATION MANUAL
FOR ELECTRICAL PARTS
Doc. No
Ver.
11.0
Date
2019-04-02
Page
83 / 98
16
DOWN lantern
DOWN lantern output in the Car
CN_W3
10
Program input
It is connected and used for program UPDATE.
Need NU-LINK
TOOL
• Connect WCOP CLOSE / OPEN button to CU63 (DCB) and CU64 (DOB).
• After setting JUMPER(J2), you need to turn power OFF -> ON to reflect
the usage.
ALL OFF
Handicap button input 1
1
Handicap button input 2
1~30
th
floor, 31~62
nd
floor
2
MAIN COP button expansion
1~30
th
floor, 31~62
nd
floor
1, 2
SUB COP button expansion
1 ~ 30
th
floor
