Hyundai Elevator WBVF - Page 85

WBVF
A ． INSTALLATION MANUAL
FOR ELECTRICAL PARTS
Doc. No
Ver.
11.0
Date
2019-04-02
Page
85 / 98
2
Load connector
PIN No.
Contents
Remark
Connector Name:
CC26
Load detection
switch is on the
floor of the Car.
1
N24
2
load 30%
B contact switch
3
load 70%
A contact switch
4
load 100%
A contact switch
5
load 110%
B contact switch
1
Voice Volume
Adjustment
Turning to the right: Volume increases
Turning to the left: Volume decreases
VR1
