WBVF
A ． INSTALLATION MANUAL
FOR ELECTRICAL PARTS
Doc. No
Ver.
11.0
Date
2019-04-02
Page
94 / 98
No.
Connector Name
Pin No.
Signal Name
Name and Function
Remark
1
CN_T2
1
B220S
220V power supply(Control Panel)
2
LITS
LIGHT output(22X)
3
FANS
FAN output (22X)
4
A220S
220V power supply(Control Panel)
5
FE
GND
6
22Y
220V power supply(building)
2
F7
FUSE (250V, 5A)
3
CC17
1
22Y
220V power supply(building)
2
FE
GND
3
FAN
FAN power(22X),output
4
CC18
1
22Y
220V power supply(building)
2
FE
GND
3
LIT
LIGHT power(22X),output
5
CN_T3
1
ULA
ULA signal, output
2
DZ1
DZ1 signal, output
3
DZ2
DZ2 signal, output
4
DLA
DLA signal, output
5
N24
Control power (0V), input
6
N24
Control power (0V), input
7
P24
Control power (+24V), input
8
P24
Control power (+24V), input
6
TB1
1
PH1
Interphone signal 1
2
PH2
Interphone signal 2
3
PH3
Interphone signal 3
4
PH4
Interphone signal 4
7
CC23B
1
P24
SAFTY RAY B power(+24V), output
2
N24
SAFTY RAY B power(0V), output
8
CC23
1
P24
SAFTY RAY A power(+24V), output
2
N24
SAFTY RAY A power(0V), output
[Table C.1 CTC Board Connector Description (1)]
