A ． INSTALLATION MANUAL
FOR ELECTRICAL PARTS
Doc. No
Ver.
11.0
Date
2019-04-02
Page
95 / 98
No.
Connector Name
Pin
No.
Signal Name
Name and Function
Remark
9
CC24B
1
P24
SAFTY RAY B control power(+24V), output
2
EE1
SAFTY RAY B control signal, input
3
N24
SAFTY RAY B control power(0V), output
10
CC24
1
EE1
SAFTY RAY B control signal, output
2
EE2
SAFTY RAY B control signal, input
3
N24
SAFTY RAY B control power(0V), output
11
CN_T21
1
ONS
Manual operation signal, input
2
ONU
Manual UP operation signal, input
3
OND
Manual DN operation signal, input
12
CN_T20
1
P24
Control power(+24V), output
2
ONS
Manual operation signal, input
3
OAT
Automatic operation signal, input
13
CC25
1
SE1
SAFTY EDGE B control signal, input
2
FE
GND
3
SE2
SAFTY EDGE B control signal, output
14
CC25B
1
N24
Control power(0V), output
2
FE
GND
3
SE1
SAFTY EDGE A control signal, input
15
CN_T19
1
N24
Control power(0V), output
2
DOB
DOOR OPEN signal, input
3
DCB
DOOR CLOSE signal, input
16
CN_T11
1
P24
Control power(+24V), output
2
DFMR
FMR relay control output
3
DFR1
FR1 relay control output
17
CN7
1
P24
Control power(+24V), output
2
N24
Control power(0V), output
3
OPL
OPEN LIMIT signal, input
18
CN8
1
P24
Control power(+24V), output
2
N24
Control power(0V), output
3
CLL
CLOSE LIMIT signal, input
[Table C.2 CTC Board Connector Description (2)]
