Hyundai Elevator WBVF - Page 96

WBVF
A ． INSTALLATION MANUAL
FOR ELECTRICAL PARTS
Doc. No
Ver.
11.0
Date
2019-04-02
Page
96 / 98
No.
Connector
Name
Pin
No.
Signal Name
Name and Function
Remark
19
S1
PUSH BUTTON (H/W RESET)
20
CN10
HHT
21
CN4
1
5V
Encoder power supply(+5V), output
2
GND
Encoder power supply(0V),output
3
AP
A phase P, input
4
AN
A phase N, input
5
BP
B phase P, input
6
BN
B phase N, input
7
-
-
8
-
-
22
CN1
DAC
23
TAP1,2
GND
GND
24
F6
FUSE(250V,10A)
25
CC16
1
A220
220V power supply(Control Panel), input
2
B220
220V power supply(Control Panel), input
26
CN12
1
U
Inverter U phase, output
2
-
3
V
Inverter V phase, output
4
-
5
W
Inverter W phase, output
27
CN_T10
1
XTSP
SPARE input (I/O)
2
DTSP
SPARE output (I/O)
28
CN_T9
1
CCH
CAN communication, input/output
2
CCL
CAN communication, input/output
29
CN_T14
1
P24
Control power +24V, output
2
CCH
CAN communication, input/output
3
CCL
CAN communication, input/output
4
N24
Control power 0V, output
[Table C.3 CTC Board Connector Description (3)]
