WBVF
A ． INSTALLATION MANUAL
FOR ELECTRICAL PARTS
Doc. No
Ver.
11.0
Date
2019-04-02
Page
97 / 98
No.
Connector
Name
Pin
No.
Signal Name
Name and Function
Remark
30
CN_T1
1
ULA
ULA signal, input
2
DZ1
DZ1 signal, input
3
DZ2
DZ2 signal, input
4
DLA
DLA signal, input
5
OAT
Automatic operation signal, input
6
ONU
Manual UP operation signal, input
7
OND
Manual DN operation signal, input
8
PH1
Interphone signal, input
9
PH2
Interphone signal, input
10
PH3
Interphone signal, input
11
PH4
Interphone signal, input
12
P24
Control power(+24V), output
13
N24
Control power(0V), output
31
JP1
1
ON
CAN communication end resistance is used.
2
COM
COMMOM connector
3
OFF
CAN communication end resistance is not used.
[Table C.4 CTC Board Connector Description (4)]
