WBVF
A ． INSTALLATION MANUAL
FOR ELECTRICAL PARTS
Doc. No
Ver.
11.0
Date
2019-04-02
Page
98 / 98
No.
Connector
Name
Pin
No.
Signal Name
Name and Function
Remark
32
CN_T12
1
P24
Control power +24V
2
DFMR
FMR Relay activation output
3
DFR1
FR1 Relay activation output
33
CC7
1
COMP
COMP Fan rope HOOK switch
2
ESON
Car upper part E-STOP switch
34
CC6
1
SAFT
SAFTY device
2
COMP
COMP Fan rope HOOK switch
35
CN_T13
1
DFL
Lower part final limit switch
2
EXIT
Emergency rescue door switch
3
ESON
Car upper part E-STOP
4
GS2
Car door switch 2
5
SAFT
SAFTY device
36
CC5
1
SAFT
SAFTY device
2
FE
GND
3
DFL
Lower part final limit switch
37
CC8
1
ESON
Car upper part E-STOP
2
GND
GND
3
EXIT
Emergency rescue door switch
38
CC4B
1
GS1
Car door switch 1
2
FE
GND
3
GS2
Car door switch 2
39
CC4
1
ESIN
E-STOP switch inside the Car
2
FE
GND
3
GS1
Car door switch 1
41
CC28B
1
EL1
Emergency light power input(DC 12V or AC)
(LED or
Incandescent lamp)
2
EL2
Emergency light power input(GND or AC)
41
CC28
1
EL1
Emergency light power output(DC 12V or AC)
(LED or
Incandescent lamp)
2
EL2
Emergency light power output(GND or AC)
42
CN_T31
1
SPK1
BGM sound adjustment signal input
2
SPK2
BGM sound adjustment signal input
43
CC11
1
BGM
BGM sound adjustment signal output
2
SPK2
BGM sound adjustment signal output
3
FE
GND
[Table C.5 CTC Board Connector Description (5)]
