82
Warning: If the next movement command is specified in the incremental mode (based on constant
pitch feed), never use the automatic servo-off mode. The current position may deviate
slightly as the servo turns off and then on again.
Caution: In push & hold operation, both the full servo control mode and automatic servo-off mode
become ineffective once the operation has completed successfully.
If the actuator has missed the load, the specified mode becomes effective.
Basically, you should not use either the full servo control mode or automatic servo-off
mode in push & hold operation.
Movement
command
Servo status
Actuator
movement
Servo on
Automatic servo-off mode
(A green LED blinks.)
Target position
T: Delay time (seconds) after positioning is
completed until the servo turns off
Position complete signal
(parameter No. 39 = 0)
Position complete signal
(parameter No. 39 = 1)
T
