7.8 Zone Signal Output
Two types of zone output signals are available: zone output (ZONE1) and position zone output (PZONE).
The boundaries defining the signal ON range are set differently for each zone output.
[1] Zone output (ZONE1) --- Set by parameter No. 1/No. 2.
[2] Position zone output (PZONE) --- Set in the “Zone boundary-“ and “Zone boundary+” fields of the
position table.
Whether these signals are available or not varies depending on the PIO pattern, as shown below.
: Available / x: Not available
PIO pattern
Signal classification
0 1 2 3 4 5
Zone output (ZONE1)

x x x
 
Position zone output (PZONE)
  
x
 
Example of use in operation) Move the actuator from the home to the 150-mm position (position 1) and
output a zone signal once the actuator enters the range between 40 mm
and 120 mm.
Method)  Zone output (ZONE1)
The signal ON range is set by the “Zone boundary+” and “Zone
boundary-” parameters.
Parameter No. 1 Zone boundary+ 120 (mm)
Parameter No. 2 Zone boundary– 40 (mm)
 Position zone output (PZONE)
The signal ON range is set in the “Zone boundary+” and “Zone
boundary-” fields of the position table.
No.
Position
[mm]
Zone boundary+
[mm]
Zone boundary-
[mm]
0 * * *
1 150.00 120.00 40.00
