65
(5) RA10C/W-RA10C type
Caution: The precision of push force at standstill is not guaranteed. The above graphs are provided
for reference purposes only. If the push force is too small, malfunction may occur during
push & hold operation due to slide resistance, etc., so exercise caution.
The maximum current-limiting value is shown in the above graphs. The minimum value is
20%.
Current-limiting value (%)
Push force (N)
Low-speed type
(Lead: 2.5 mm)
Current-limiting value (%)
Push force (N)
Medium-speed type
(Lead: 5 mm)
Current-limiting value (%)
Push force (N)
High-speed type
(Lead: 10 mm)
