[4] D-sub, 9-pin connector (RS232C)
A connection port with a PLC’s communication module. It can also be connected to a PC. For the
communication cable, use the RS232C cross cable specified below.
[5] Mini DIN, 8-pin connector (RS485)
A connection port with a teaching pendant or PC. For the communication cable, use the cable
(equipped with a RS232C/RS485 converter) that comes with the PC software (RCM-101-MW).
[6] PORT switch
A switch for enabling/disabling the mini DIN connector.
Set the switch to the ON position if a device is connected to the mini DIN connector, or to the OFF
position if no device is connected.
[7] Monitor LEDs
LED1 --- Lit when the controller is transmitting
LED2 --- Lit when the RS232 is transmitting
