183
Appendix
No. Category Name Unit Recorded data
41 c
Operating-mode input disable selection
[0: Enable / 1: Disable]
-
42 b Enable function [0: Enable / 1: Disable] -
43 b
Polarity of home check sensor input
[0: Contact a / 1: Contact b]
-
45 c Silent interval multiplier -
46 b Speed override %
47 b PIO jog speed mm/sec
48 b PIO inching distance mm
49 b PIO inching distance 2 mm
50 b Load output judgment time msec
51 b
Torque check range [0: Enable / 1:
Disable]
-
53 b Default stop mode -
77 b
Ball screw lead length
mm
78 b
Axis operation type
-
79 b
Rotational axis mode selection
-
80 b
Shortcut selection for rotation
-
83 b
Absolute unit [0: Not used / 1: Used]
-
84 C
Fieldbus operation mode
-
85 C
Fieldbus node address
-
86 C
Fieldbus baud rate
-
87 C
Network type
-
88 a
Software limit margin
mm
90 C
Fieldbus I/O format
-
91 b
Current-limiting value at standstill after
missing work in push & hold operation
-
