IBM 4820 User Manual

Asm–
Index
Part
Number
Units Description
–6 47L7229 1 MSR, 3-track, pearl white (non 2xx, 5xx models)
–6 29R0856 1 MSR, 3-track, iron gray (only for models 2xx and 5xx)
–6 07K6136 1 MSR, 3-track, iron gray (non 2xx, 5xx models)
–6 07K6137 1 MSR, JUCC, iron gray (non 2xx, 5xx models)
–6 41K6061 1 MSR, JUCC, iron gray (only for models 2xx and 5xx)
–6 47L7230 1 MSR, JUCC, pearl white (non 2xx, 5xx models)
–6 41K6059 1 MSR, JUCC, pearl white (only for models 2xx and 5xx)
–7 00P1405 1 Keypad/3-track MSR, pearl white
–7 00P1408 1 Keypad/JUCC MSR, pearl white
–7 29R0852 1 Keypad/3-track MSR, iron gray
–8 47L8747 1 Cable, analog video 0.8 m (models 42D, 42T, 4FD, 4FT, 46D, 46T, 4WT, 4GT only)
–8 25L7095 1 Cable, analog video 1.8 m (models 42D, 42T, 4FD, 4FT, 46D, 46T, 4WT, 4GT only)
–8 25L7094 1 Cable, analog video 3.8 m (models 42D, 42T, 4FD, 4FT, 46D, 46T, 4WT, 4GT only)
–9 95F3192 1 Cable, RS-485 Touch/MSR/Keypad, 0.8 m (models 46D/46T only)
–9 48G9020 1 Cable, RS-485 Touch/MSR/Keypad, 1.8 m (models 46D/46T only)
–9 95F3191 1 Cable, RS-485 Touch/MSR/Keypad, 3.8 m (models 46D/46T only)
–9 07K6154 1 Cable, EIA-232 Touch/MSR, PS/2 Keypad, 1.8 m (model 42T only)
–9 07K6092 1 Cable, EIA-232 Touch/MSR, PS/2 Keypad, 3.8 m (model 42T only)
–9 07K6156 1 Cable, EIA-232 Touch/MSR, 1.8 m (model 4FT only)
–9 10J0860 1 Cable, EIA-232 Touch/MSR, 3.8m (model 4FT only)
–9 01L1636 1 Cable, USB, 0.8 m (models 48D, 48T, 4WT, 4GT only)
–9 07K5153 1 Cable, USB, 1.8 m (models 48D, 48T, 4WT, 4GT only)
–9 01L1637 1 Cable, USB, 3.8 m
–9 14J1052 1 Cable, Video, 0.8 m Analog
–9 14J1108 1 Cable, Video, 1.8 m Analog
–9 14J1054 1 Cable, Video, 3.8 m Analog
–9 66P0406 1 Cable, Video, 1.0 m VGA-VGA (models 10D, 1FR only)
–9 66P0407 1 Cable, Video, 2.6 m VGA-VGA (models 10D, 1FR only)
–9 66P0408 1 Cable, Video, 1.0 mVGA-DVI (models 10D, 1FR only)
–9 66P0409 1 Cable, Video, 3.8 m VGA-DVI (models 10D, 1FR only)
–9 14J0932 1 Cable, standard USB, 1.8 m
–9 47L8705 1 Cable, standard USB, 3.8 m
–9 99J9355 1 Cable, analog VGA to DVI, 0.3 m
– Models 2xx and 5xx:
– 14J0980 1 Cable, EIA-232, Touch only, 0.8 m
– 14J0979 1 Cable, EIA-232, Touch only, 1.8 m
– 14J0978 1 Cable, EIA-232, Touch only, 3.8 m
– 14J0972 1 Cable, EIA-232, Touch and MSR, 0.8 m
– 14J0971 1 Cable, EIA-232, Touch and MSR, 1.8 m
– 14J0970 1 Cable, EIA-232, Touch and MSR, 3.8 m
– 14J0976 1 Cable, EIA-232, Touch, Keypad/MSR, 0.8 m
– 14J0975 1 Cable, EIA-232, Touch, Keypad/MSR, 1.8 m
– 14J0974 1 Cable, EIA-232, Touch, Keypad/MSR, 3.8 m
– 14J1142 1 Cable assembly (1.8 m) for SurePOS 700 speaker kit
– 14J1143 1 Cable assembly (3.8 m) for SurePOS 700 speaker kit
– 29R0933 1 Speaker/microphone kit, factory, pearl white
–10 07K4039 1 Speaker kit attachment cables (set of 2) Speaker and Microphone (1.8 m)
–10 07K4040 1 Speaker kit attachment cables (set of 2) Speaker and Microphone (3.8 m)
– Power cords for models 4xx:
–11 76H3516 1 v Power cord, US
–11 76H3514 1 v Power cord, Argentina/Australia/New Zealand
–11 76H3518 1 v Power cord, Austria/Belgium/France/Germany
–11 76H3520 1 v Power cord, Denmark
Assembly 1: (continued)
Update November 2005
84 4820 Planning, Installation and Service Guide
||||
||||
||||
||||
||||
||||
||||
||||
||||
||||
||||
||||
||||
||||
||||
||||
||||
||||
||||
||||
||||
