Identifying the 4820 I/O ports
This section identifies the input/output ports of the various 4820 models. See
Figure 12 on page 15.
Note:
This section does not show all possible configurations.
Models 2xx, 5xx
Models 42T, 4FT
AB
C
D
Figure 14. Model 2xx EIA-232 I/O ports
AB E F
Figure 15. Model 5xx USB I/O ports
BA
GD
Figure 16. Models 42T, 4FT I/O ports
Installing the IBM 4820
Update November 2005
Chapter 2. Installing the IBM 4820 17
