IBM 4820 User Manual

Asm–
Index
Part
Number
Units Description
2–1 66P0402 1 Hinge cover, pearl white
–1 66P0403 1 Hinge cover, iron gray
–1 29R0945 1 Hinge cover, 15″ integrated stand pedestal, pearl white
–1 29R0947 1 Hinge cover, 15″ integrated stand pedestal, iron gray
–2 43P8624 1 Cable cover, pearl white
–2 10N1206 1 Cable cover, iron gray
–3 47L8732 1 Hinge assembly
–3 1 Hinge assembly, 15″ integrated pedestal
–4 43P8586 1 Arm cover, pearl white
–4 10N1205 1 Arm cover, iron gray
–5 25L7025 1 Integrated mount, 4694 (all except models 154, 254)
–5 07K5148 1 Integrated mount, 4694, DBCS models 154, 254
–5 07K5158 1 Integrated mount, 4800 models 73x, 75x
–5 57P4329 1 Integrated mount, tall, pearl white
–5 42P8077 1 Integrated mount, short, pearl white
–5 10N1209 1 Integrated mount, tall, iron gray, 4800 models 720, 740, 780
–5 10N1203 1 Integrated mount, short, iron gray, 4800 models 720, 740, 780
–5 29R0955 1 15″ integrated stand pedestal, pearl white
–5 29R0956 1 15″ integrated stand pedestal, iron gray
–6 57P4338 1 Filler panel kit, wide 4694
–6 57P4336 1 Filler panel kit, wide 4800, pearl white
–6 10N1309 1 Filler panel kit, wide 4800, iron gray
–7 57P4337 1 Filler panel kit, narrow 4800, pearl white/storm gray
–7 10N1317 1 Filler panel kit, narrow 4800, iron gray
–8 30R0226 1 VESA mount, pearl white
–8 30R0227 1 VESA mount, iron gray
–8 29R0948 1 15″ VESA bracket
–9 47P6405 1 SurePoint stand for SurePOS 500/600, iron gray
–10 07K6080 1 Freestanding pedestal (distributed), pearl white
–10 07K6120 1 Freestanding pedestal (distributed), iron gray
–11 47L8741 1 Pole cover, litho gray, 4694
–11 47L8742 1 Pole cover, storm gray, 4800
–12 07K4036 1 Distributed mount, 352 mm, tall, storm gray
–12 07K4037 1 Distributed mount, 240 mm, short, storm gray
–12 25L7036 1 Distributed mount, 352 mm, tall, litho gray
–12 25L7037 1 Distributed mount, 240 mm, short, litho gray
– 14J1355 1 Distributed Mount, SurePoint stand, SurePOS 4840 Models 533/543/565
– 47P6405 1 Distributed Mount, SurePOS Models 500/600
–13 43P8607 1 Stiffening plate, wide 4694
–14 29R0944 1 15″ integrated stand bottom cover, pearl white
–14 29R0946 1 15″ integrated stand bottom cover, iron gray
– Parts not shown:
– 10N1348 1 v Hold down screws, 4800 models 720, 740, 780 with slant tray
– 10N1349 1 v Hold down screws, 4800 models 720, 740, 780 without slant tray
– 57P4332 1 v Hold down screws, wide 4694
– 57P4334 1 v Attaching hardware, stiffening plate, wide 4694
– 66P0404 1 v Button cover, iron gray (model 1FR, 26x, 56x)
– 40N4616 1 v Button cover, pearl white (model 10D, 2Wx, 5Wx)
Assembly 2: (continued)
Update November 2005
Appendix A. Field-replaceable units 87
||||
||||
||||
||||
||||
||||
||||
||||
||||
||||
||||
||||
