174
Chapter 6 Hammer Phasing Adjustment
13. Press
Enter. The phasing index (followed by an asterisk) will move up to
the top line of the display.
14. Press Scroll↑ or Scroll↓ to increase or decrease the phasing index, then
press Enter to activate the value as it prints. Continue to increase or
decrease the phasing index until the pattern of Hs appears as shown
below:
15. When the print pattern is acceptable, press Stop. Printing stops, and the
printer automatically enters the current phase index value into NVRAM.
The display shows “NOT READY”.
16.
Press Scroll↑ + Scroll↓ to lock the Enter key.
17.
Close the printer cover. Press Start to put the printer into READY mode.
NOTE: If you changed the phasing value, power down the printer, remove
the shuttle cover, and write the new phase value on the aluminum
shuttle casting.
Needs
Adjustment
Correct
Needs
Adjustment
To Next Page
