310
Appendix A Circuit Board And Cable Pinouts
Cable Assembly, Operator Panel
PIN 1
PIN 1
PIN 8
PIN 8
(Gray)
(Brown)
(Gray)
(Brown)
NOTE: If you replace the control panel cable,
you must install two ferrite shielding beads.
See Appendix I.
14H5300
