230
Chapter 7 Section I: Replacement Procedures
Paper Ironer
Removal
1. Remove the shuttle frame assembly (page 242).
2. Move the forms thickness lever to the open position.
3. Push the ends of the paper ironer toward the rear of the printer,
disengage the tabs, then lift it up and out (page 276, Figure 51).
Installation
NOTE: The black tape on the paper ironer faces the paper detector switch
assembly.
1. Position the paper ironer so that the black tape is on the side that faces
the paper detector switch assembly. (See page 276, Figure 51.)
2. Push the paper ironer down into the slots until the tabs engage.
3. Install the shuttle frame assembly (page 242).
4. Return the printer to normal operation (page 153).
<2> Over time the upper edge of the paper ironer can become
sharp. To avoid cutting yourself, handle the paper ironer on
the sides.
