368
Appendix J Introduction
Introduction
The SureStak Power Stacker is an option available for cabinet model printers.
Most of the stacker assembly is inside the cabinet, so usually you will have to
remove the stacker assembly from the printer in order to service it or replace
components.
The power paper stacker is designed to work with forms from 5 to 12 inches
(12.7 to 30.5 cm) long. Using longer or shorter paper can cause error
messages and unpredictable behavior of the stacker.
This appendix consists of three parts:
• An overview of stacker operation.
• Removal/installation instructions for the power stacker assembly and
components that require the most frequent replacement.
• An illustrated parts breakdown (IPB) showing how the entire power
stacker unit is assembled. The IPB also lists the part numbers for
replaceable parts.
NOTE: Only replaceable parts have part numbers in the IPB. If you need to
replace a part for which no part number is shown, replace the entire
power stacker assembly.
Stacker Operation
The power stacker mechanically directs the paper from the printer to the
paper stack. It is mounted in the rear of the cabinet and has its own control
panel.
This section explains briefly how to use the power stacker.
Component Locations
Figure 59 shows the names and locations of the major components of the
paper stacker.
