Chapter 7 Section I: Replacement Procedures
Cover Assembly, Top, Pedestal Model
Removal
1. Prepare the printer for maintenance (page 152).
2. Remove the operator panel (page 228).
3. Remove five screws and the control panel bracket. (See Figure 43, page
256, items 3 and 4.)
4. Loosen the two captive #2 Phillips screws in the lower front corners of the
top cover. (See Figure 43, page 256, item 14.)
5. Loosen, but do not remove, the two #2 Phillips hold-down screws on the
rear of the printer. (See Figure 43, page 256, item 8.)
6. Lift the top cover assembly off the printer base.
Installation
1. To install the top cover assembly, reverse steps 2 through 6 of the
removal procedure.
2. Return the printer to normal operation (page 153).
