IBM 6400 Maintenance Information Manual

10/100Base-T LEDs And DIP Switches
55
STAT (Status) Indicator In Run And Auto Reset Modes
Run Mode is the normal operating state of this interface. Auto Reset mode is
entered when the watchdog timer is triggered and the print server resets itself.
In either mode, the STAT LED flashes at a varying rate, depending on
whether the unit IP address is configured:
NET (Network) Indicator
The NET LED displays the status of the network link:
DIP Switches
On the back of the 10/100Base-T interface inside the printer, there are two
DIP switches labeled 1 and 2. The functions of the DIP switches are explained
in Table 3.
STAT Rate Indication
OFF Flashes ON
once per second
Normal Mode, IP address
configured
OFF Flashes ON 2
times per second
IP address not configured
ON Flashes OFF
once per second
Download (MOS)
ON Flashes OFF
twice per second
Error
NET Rate Indication
ON Constantly Indicates link integrity
ON Flashes OFF 1/3
second
Flashes off 1/3 second every time a
data packet is transmitted
OFF Constantly Network connection has been severed
