Chapter 7 Section I: Replacement Procedures
Figure 32. Hammer Bank Cover Assembly / Ribbon Mask
1
2
3
4
5
6
7
8
9
10
11
12
123546
Early Models
Later Models
Hammer Bank Cover
(Thick Plate)
Ribbon Mask Torque Sequence
Hammer Bank Cover Torque Sequence
Ribbon Mask
(Thin Plate)
Hammer Bank Cover
Assembly
Ribbon Mask
Clamp Plate (3)
Hammer Bank Cover
Screw (6)
Screw (12)
