Chapter 7 Section I: Replacement Procedures
Installation
ATTENTION
To prevent electrostatic damage to electronic components, wear a
properly grounded static wrist strap when handling circuit boards, the
shuttle frame assembly, and any other electronic component.
NOTE:
Flash SIMMs from one CMX controller board must be placed in the
same slot on a replacement CMX controller board. Installing flash
memory from one controller board to another does not transfer all
operating system software, so you must download the emulation
again.
NOTE: Part numbers for pre-written flash memory and security modules are
listed in Table 8 and Table 9.
1. Insert the memory module into the correct socket on the CMX controller
board:
a. Position the SIMM so the notched end is toward the right-hand side of
board. (See Figure 35, page 220.)
b. Press the SIMM into the socket with the top of the SIMM angled
away
from the center of the board. When the SIMM is seated in the socket,
gently push on the ends until it locks in the upright position.
2. Install the security module. (See Figure 35, page 220.)
3. Cabinet Model: Install the paper guide assembly (page 229).
Pedestal Model: Install the top cover assembly (page 204).
4. Download the emulation (page 176).
5. Return the printer to normal operation (page 153).
6. Using the configuration printouts you made as step 1 of the removal
procedure, reset and save the printer configurations. (Refer to the
Setup
Guide
.)
