Illustrations Of Printer Components
251
Item
No.
Part No.
(Order No.)
Description Notes
1 24H8961 Top Cover Kit Includes mounting hardware
2 57G1492 Window, Top Cover Not visible in Figure 40
3 14H5567 Wireform Paper Guide Assembly Includes mounting hardware
4 24H8960 Rear Door Kit Includes item 14
5 24H8959 Front Door Kit Includes item 14
6 57G1485 Caster, with Brake Two at front
7 57G1486 Caster, without Brake Two at rear
8 14H5603 Logo, 6400
9 30H4008 Wire Rope, Front and Rear One on each door (Rear not
shown in Figure 40)
10 30H3986 Shipping Container Kit Cabinet models only
(Not shown in Figure 40)
11 14H5572 Hardware Kit Not shown in Figure 40
12 63H7510 Door Seal Kit
13 63H7398 Top Cover Seal Kit
14 93F7037 Hinge Plate, Top Included in items 4 and 5
15 57G1484 Hinge Plate, Bottom
