Illustrations Of Printer Components
259
Item
No.
Part No.
(Order No.)
Description Notes
1 14H5235 Shroud Assembly, Air Shuttle Cover Assembly
2 Ref Screw, Captive (2) 10-24x.62 with O-ring,
.125x.250x.06
3 Ref Screw, Thread Forming (4) 6-32x.25
4 Ref Barrier Shield
5 14H5271 Paper Guide Assembly Models 004, 005, 008, 009,
012, 014
6 Ref Screw, w/Lock Washer (3) 6-32x.25 and #6 Flat Washer
7 14H5174 Platen/Paper Feed Cover Kit Paper feed belt cover shown
in Figure 44. Platen open belt
cover: item 24, page 276.
8 57G1468 Belt, Timing, 050P, 100 Teeth Paper Feed Belt
9 08H7954 Anti-Static Brush Kit
10 Ref Power Supply Shield Taped to card cage along
upper edge
11 14H5179 Paper Scale
