Illustrations Of Printer Components
261
Item
No.
Part No.
(Order No.)
Description Notes
1 14H5235 Shroud Assembly, Air Shuttle Cover Assembly
2 Ref Screw, Captive (2) 10-24x.62 with O-ring,
.125x.250x.06
3 Ref Screw, Thread Forming (4) 6-32x.25
4 Ref Barrier Shield
5 63H5116 Paper Path Assembly Models 04P, 05P, 08P, 09P
6 08H7954 Anti-Static Brush Kit
7 Ref Power Supply Shield Taped to card cage along
upper edge
8 57G1468 Belt, Timing, 050P, 100 Teeth Paper Feed Belt
9 14H5174 Platen/Paper Feed Cover Kit Paper feed belt cover shown
in Figure 45. Platen open belt
cover: item 24, page 276.
10 14H5179 Paper Scale
