IBM 6400 - Page 272

272
Chapter 7 Section II: Illustrated Parts Lists
Figure 49. Magnetic Pickup Unit (MPU) and Extension Spring
0.010
+
.001 inch
(0.254 + .025mm)
<21> Make sure the extension
spring does not touch the MPU
cable after installation.
Spring Lug (Do not
remove grease)
Spring Lug (Do not
remove grease)
4
1
2
3
