Illustrations Of Printer Components
277
Item
No.
Part No.
(Order No.)
Description Notes
1 Ref Setscrew Part of item 25
2 Ref Bracket, Platen (2) Part of item 25
3 57G1469 Ironer Assembly Reverser Paper Feed
4 Ref Screw, Thread Forming (3) 6-32x.25
5 57G1571 Bracket, Ironer
6 Ref Plate, Ironer
7 08H7936 Platen Assembly
8 Ref Washer, Flat (2) Part of item 25
9 Ref Screw (2) Part of item 11
10 Ref Washer, Flat #4 (2) Part of item 11
11 14H5280 Platen Switch Kit Platen Interlock Switch
12 Ref Screw, Socket Cap, 6-32x.75 Part of item 15
13 Ref Washer Part of item 15
14 Ref Nut Part of item 15
15 63H7478 Platen Lever Kit
16 Ref Spring, Extension 1.12L Part of item 25
17 Ref Link, Spring Part of item 25
18 Ref Bearing, Nylon .376 Part of item 25
19 Ref Bracket, Switch Mount Part of item 11
20 Ref Wear Saddle, Platen (2) Part of item 25
21 57G1514 Platen Pulley, Driven
22 Ref Screw, Socket Cap, 6-32x.44 Part of item 21
23 57G1467 Belt, Timing, 312W, 87 Teeth Platen Open Belt
24 14H5174 Platen/Paper Feed Cover Kit Platen open belt cover shown
in Figure 51. Paper feed belt
cover: page 258, item 7.
25 14H5169 Platen Hardware Kit
26 Ref Platen Washer Part of item 25
