Illustrations Of Printer Components
285
Item
No.
Part No.
(Order No.)
Description Notes
1 Ref Screw, Connector Cover (2)
2 Ref Cover Plate, Centronics
3 Ref Ferrite Clamp See also Appendix I
4 Ref CMX Controller Board
5 14H5287 Centronics I/O Cable Assembly
6 24H8995 Ethernet LAN PCBA, 10Base-T
7 24H8994 Ethernet LAN PCBA, 10Base2
8 02N8315 Ethernet LAN PCBA, 10/100Base-T
9 Ref Rear of Card Cage
10 Ref Screw (2)
To Next Page
