372
Appendix J Stacker Operation
Legend:
1) Paper Length Indicator
2) Paddle Shaft
3) Bearing Bracket
Figure 62. Setting Paper Length
Loading and Starting the Power Stacker
1. Press the
FORM FEED
key on the the stacker control panel and hand
feed the paper down into the paper throat. Continue to advance the paper
until it reaches the wire tent and there are 3 to 5 extra sheets in the
stacker. Make sure the paper passes through the throat of the paper
stacker. (See Figure 63.)
Figure 63. Paper Path in the Power Stacker
2. Stack the 3 to 5 sheets of paper on top of the wire paper tent, making sure
the paper lies with the natural fold.
$
$
1
2
3
To Next Page
