393
5. Lift the loose end of the constant force spring and let it curl up on the
outside of the remaining spring and drum. (See Figure 83.)
6. While holding the drum tightly, continue to curl the spring until it is
completely unwound from the drum. (See Figure 83.)
7. To install a new constant force spring, reverse the steps of this procedure.
Legend:
1. Spring
2. Drum
Figure 83. Removing the Constant Force Spring from the Drum
1
2
