IBM 6400 Maintenance Information Manual

400
Appendix J Illustrated Parts Breakdown
Item
No.
Part No. Description Notes
5 Ref Flanged Bearing Part of item 36
6 24H8966 Paper Deflector
7 Ref Clip-On Bearing Part of item 36
8 Ref Screw, Torx, 6-32 x .25 Part of item 36
9 Ref Screw, Shoulder, 10-32 Part of item 36
10 24H8968 Timing Belt
11 24H8996 Shaft, Lift
12 24H9002 Pulley, Timing Belt
13 24H9001 Pulley, Motor
14 57G1521 Clip, Grounding
15 24H8969 Motor
20 24H8970 Constant Force Spring
25 24H8971 Chain Mount chains outboard of
shafts
30 Ref Nylon Plug
35 24H8973 Cable
36 24H9004 Stacker Hardware Kit Kit not illustrated
37 Ref Screw, Shoulder, 8-32 Part of item 36
38 01P4699 Power Stacker Limit Switch Kit Replaces earlier limit
switches
40 170870-901 Limit Switch Assembly Replacement switch if item
38 is installed
24H8974 Control Panel Assembly Figure 78, page 388
Ref Rail Cable, Power Stacker See page 321
24H8975 Power Cable, Power Stacker See page 320
24H8976 Logic Cable, Power Stacker See page 319
Ref Frame Cable, Power Stacker See page 318
24H8962 Rear Door, Extended, Power Stacker Not illustrated
24H8963 RE Ship Kit, Printer w/Power Stacker Not illustrated
