418
memory modules, 217
multi-platform interface, 194
network print server, 226
operator panel assembly
cabinet model, 227
pedestal model, 228
paper detector switch assembly, 246
paper feed drive motor, 221
paper feed timing belt, 188
paper guide assembly, 229
paper ironer, 230
platen, 231
platen interlock switch assembly, 247
platen open belt, 189
platen open motor, 223
power supply circuit board, 192
print server, network, 226
resistors, terminating, 235
ribbon drive motor, 225
ribbon guide assembly (L/R), 237
ribbon hub, 238
shuttle frame assembly, 242
splined shaft, 239
support shaft, 241
tractor (L/R), 248
Reset Mode, 55
Reset, soft vs. hard, 145
RESETTING ... PLEASE WAIT, 106
RESETTING... PLEASE WAIT, 180
Resistors, terminating
location of, 236
RESTORING BOOT CODE, 107
RESTORING BOOT CODE (message), 180
Ribbon
drive motor, replacement, 225
guide assembly (L/R), replacement, 237
guide assembly, alignment, 166
hub, replacement, 238
mask, replacement, 200
specifications, 327
RIBBON OUT OF INK / CHANGE RIBBON, 107
Run Mode, 55
S
Safety
inspection guide, 341
notices, defined, 17
SECURITY CODE VIOLATION, 180
Security module, location, 220
Self Test
10/100Base-T, 54
Self-tests
customer engineer (CE), 134
operator print, 132
printer information menu, 143
SENDING PROGRAM TO EC PROCESSOR, 107,
180
SERVICE /, 107
Service checks
customer’s power source
, 345
power on/off verification
, 345
print interlock
, 345
print mechanism
, 343
printer power cable
, 345
Set shuttle speed
, 182
Shaft
splined, replacement
, 239
splined, skew adjustment
, 168
support, replacement
, 241
Shuttle
cover assembly, replacement
, 203
frame assembly, replacement
, 242
speed setting
, 182
Signal mnemonics
, 347
SIMMs, location and replacement
, 217
Soft reset
, 145
Software
loading into flash memory, 176
SOFTWARE ERROR* / Cycle power, 107
Specifications
dimensions, printer, 329
duty cycle, 336
electrical, 330
environmental, 329
interfaces, 336
