Table 2. Firmware Checkpoints. (continued)
Checkpoint Description Action/ Possible Failing FRU
E1E1 Flash update complete See “Unresolved Checkpoint Problems”
on page 85.
E1E2 Initialize system I/O Go to MAP 1540: Minimum
Configuration, “Step 1540-24” on
page 81.
E1E3 PReP boot image initialization. See “Unresolved Checkpoint Problems”
on page 85.
E1E4 Initialize Super I/O with default values. Go to MAP 1540: Minimum
Configuration, “Step 1540-24” on
page 81.
E1E5 XCOFF boot image initialization. See “Unresolved Checkpoint Problems”
on page 85.
E1E6 Set up early memory allocation heap. See “Unresolved Checkpoint Problems”
on page 85.
E1E7 PE boot image initialization. See “Unresolved Checkpoint Problems”
on page 85.
E1E8 Initialize primary diskette drive (polled
mode).
See “Unresolved Checkpoint Problems”
on page 85.
E1E9 ELF boot image initialization. See “Unresolved Checkpoint Problems”
on page 85.
E1EA Corrupted firmware image detected
while loading from diskette.
1. Ensure that the diskette installed
contains recovery image appropriate
for this system unit.
Refer to “Checking the Current
Firmware Levels” on page 349.
2. If the diskette is installed with the
correct recovery image, then
suspect:
a. Diskette
b. Diskette drive
c. Diskette cable
d. Replace the system board.
Location: P1
(See notes on page 115.)
3. See “Unresolved Checkpoint
Problems” on page 85.
